3.7V 3400mAh 10A High Rate 18650 Lithium Ion Battery For Consumer Electronics
Product Details:
| Place of Origin: | Japan |
| Certification: | UN38.3 MSDS CB CE BIS |
| Model Number: | NCR18650B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1000PCS |
|---|---|
| Packaging Details: | Industrial Pakcage |
| Delivery Time: | 35 working days |
| Payment Terms: | L/C,T/T,Western Union |
|
Detail Information |
|||
| Battery Type: | Rechargeable Lithium Ion Battery | Nominal Voltage: | 3.7V |
|---|---|---|---|
| Typical Capacity: | 3400mAh | Weight: | 48g |
| Dimension: | Diameter :18mm Height :65mm | Discharge Rate: | 10A |
| Working Temperature: | -20 To 80 Degree | Cycle Life: | More Than 500 Cycles |
| Highlight: | 18650 3.7 V 3400mah Battery,18650 3400mah 3.7 V,18650 Lithium Ion Battery |
||
Product Description
3.7V 3400mAh 10A High Rate 18650 Lithium ion Battery
Features
- High Energy Density: Offers 3400mAh capacity in standard 18650 size
-
High Rate Capability: Supports up to 10A continuous discharge current
-
Long Cycle Life: Maintains performance over 500+ charge cycles
-
Stable Voltage Output: Consistent 3.7V nominal voltage throughout discharge
-
Low Self-Discharge: <3% per month at room temperature
-
No Memory Effect: Can be recharged at any state without capacity loss
Specification
| Typical capacity | 3400mAh |
| Nominal Voltage | 3.7V |
| Dimensions | 18mm (Diameter) × 65mm (Height) |
|
Max. DisCharge Current |
10A |
|
Discharge Cut-off Voltage |
2.5V |
| Weight | 48g |
| Cycle Life | ≥500 cycles |
| Operating Temperature |
Charge: 0°C to 60°C; Discharge: -20°C to 80°C |
| Storage Temperature |
-20°C to 50°C (Recommended: 20-25°C) |
| Internal Resistance | ≤25mΩ |
| Self-Discharge Rate | <3% per month |
| Warranty | 12 months |
Applications
- High-Power Flashlights: Tactical and professional lighting equipment
-
Power Tools: Drills, saws, and other cordless tools
-
Portable Power Banks: High-capacity mobile charging solutions
-
Electric Vehicles: E-bikes, scooters, and other light electric vehicles
-
RC Hobbies: Drones and remote-controlled vehicles
-
Medical Devices: Portable medical equipment
-
UPS Systems: Uninterruptible power supplies
-
Consumer Electronics: Laptops, cameras, and audio equipment
Warnings & Precautions
- Use only Li-ion specific chargers with proper voltage/current regulation
- Never exceed 4.2V charging voltage
- Do not charge at temperatures below 0°C or above 45°C
- Discontinue use if battery becomes hot, swollen, or shows damage during charging
- Avoid discharge below 2.5V cut-off voltage
- Do not exceed 10A continuous discharge current
- Never short-circuit the battery terminals
- Allow battery to cool between high-drain applications
- Store at 30-50% charge state for long-term storage
- Keep in cool, dry environment (20-25°C ideal)
- Keep away from water and moisture
