2S 3850mAh LiPo Battery - 7.4V 28Wh for Mini Drones, FPV Whoops, Small RC Planes/Cars - XT30 Connector
Detalhes do produto:
| Lugar de origem: | China |
| Número do modelo: | LiPo 2S |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 100 unidades |
|---|---|
| Detalhes da embalagem: | Gaiola Industrial |
| Tempo de entrega: | 35 dias úteis |
| Termos de pagamento: | L/C, T/T, Western Union |
|
Informação detalhada |
|||
| Tensão: | 7.38V | Capacidade: | 3850mAh (3,85Ah) |
|---|---|---|---|
| Energia: | 28,41Wh | Corrente de carga padrão: | 1,0C (3,9A) |
| Corrente de carga rápida: | 2,0C máx. (7,7A) | Resistência Interna: | mΩ do ≤ 20 |
| Peso: | 139g | Dimensões: | 85,0x30,0x50,0mm |
Descrição de produto
2S 3850mAh LiPo Battery - 7.4V 28Wh for Mini Drones, FPV Whoops, Small RC Planes/Cars - XT30 Connector
Features
- Optimized Form Factor: The 85x30x50mm dimensions offer a high capacity in a slim, space-efficient package ideal for built-in battery compartments.
- Excellent Energy-to-Weight Ratio: At 139g, it provides a high energy density (~204 Wh/kg), favoring portable applications.
- Stable Discharge Performance: LiPo chemistry ensures a relatively flat voltage curve during discharge, providing consistent power.
- Custom Voltage Platform: The 7.38V nominal voltage may be optimized for specific device electronics to improve efficiency or circuit design.
Specifications
| Nominal Voltage | 7.38 V |
| Nominal Capacity | 3850 mAh (3.85 Ah) |
| Weight | 139 g |
| Dimensions | 85 x 30 x 50 mm |
| Energy | 28.41 Wh |
|
Charge Voltage |
8.5V |
| Standard charge current |
|
| Fast Charge Current |
|
| Working teerature | Charge:5°C to 40°C |
| Discharge:-10°C to 60°C |
Applications
- Portable Consumer Electronics: High-capacity power for handheld gaming devices, portable speakers, or specialized electronic gadgets.
- Compact Lighting Equipment: LED video lights, camera flash units, or work lights requiring slim battery packs.
- Mini/Micro Drones & FPV Equipment: Smaller drones or FPV systems where the 7.38V specification meets specific power requirements.
- Custom DIY Projects & Robotics: Power source for custom-built electronics, small robots, or IoT devices where standard voltages are not optimal.
- Backup Power Solutions: Uninterruptible power supply (UPS) for low-power networking or computing devices.
Warnings & Precautions
Charging
- Use a LiPo Charger: ONLY use a computerized LiPo balance charger set to 2S mode.
- Verify Settings: Confirm charger settings: LiPo, 2S (or 7.4V), Current ≤ 3.9A (1C) before starting.
- Supervised Charging: Charge in a safe, fire-resistant location. Never charge unattended.
- Balance Charge: Always use the JST-XH balance port during charging to maintain equal cell voltage.
- Stop if Abnormal: Disconnect immediately if the battery swells, gets hot, smells, or shows any damage.
Discharging
- Voltage Limits: DO NOT discharge below 6.0V (3.0V per cell). DO NOT charge above 8.4V (4.2V per cell).
- Temperature: Operate within -10°C to 60°C. Ideal operating range is 20°C to 45°C. Allow to cool before charging.
- Physical Damage: Inspect before each use. Do not use if punctured, deformed, leaking, or with damaged wires.
- Short Circuit Prevention: Keep terminals clean and insulated. Always use connector caps when not in use.
- Environment: Avoid exposure to water, rain, and extreme temperatures.
Storage
- Storage Voltage: For storage longer than one week, maintain battery at 3.8V - 3.85V per cell (7.6V - 7.7V total).
- Storage Conditions: Store in a cool, dry place (10°C - 25°C is ideal) inside a LiPo safety bag or fireproof container.
- Transport: Protect terminals from shorting. For air travel, this sub-100Wh battery generally complies with carry-on regulations when properly installed or protected.
